3S 10A Lithium Battery Protection BMS Module for 3.7V NMC cells without Nickel Strip

The 3S 10A Lithium Battery BMS Module protects 3-cell (3S) 3.7V NMC battery packs with overcharge, over-discharge, short circuit, and overcurrent protection. It supports 10A continuous discharge and ensures the safety and longevity of lithium battery packs used in DIY battery packs, e-bikes, power banks, and other lithium-powered devices.

3S 10A Lithium Battery BMS Module Features & Specifications:

1. Working Current: 5A-10A
2. Maximum Peak Current: 10A
3. Overcharge Voltage Range: 4.25V ± 0.05V per cell
4. Over-Discharge Voltage: 2.7V ± 0.1V per cell
5. Quiescent Current: <30µA


Package Includes:

1 x 3S 10A Lithium Battery Protection BMS Module for 3.7V NMC cells with Nickel Strip
